ISOLED LED NEON919/950 CCT flex stripe B13H10 for tile profiles, 24V DC, 6W|6W, IP67, 300cm
€107.58 *
Content:
3 m
(€35.86 *
/ 1 m)
Availability:
Currently not available.
Expected to be available again in 8 days.
Expected to be available again in 8 days.
Currently not available
Item number: 111017165
EAN: 9009377158247
MPN: 116266
ISOLED LED NEON919/950 CCT flex stripe B13H10 for tile profiles, 24V DC, 6W|6W, IP67, 300cm, 240... more
All information about the product:
"ISOLED LED NEON919/950 CCT flex stripe B13H10 for tile profiles, 24V DC, 6W|6W, IP67, 300cm"
ISOLED LED NEON919/950 CCT flex stripe B13H10 for tile profiles, 24V DC, 6W|6W, IP67, 300cm, 240Technical data:
| Length: | 3000 mm |
| Width: | 13 mm |
| Height: | 10 mm |
| LED type: | SMD2835 |
| Nominal voltage: | 24 V |
| Nominal power: | 12 W |
| Rated power: | 6 W |
| Colour temperature: | 1900K - 5000K |
| Beam angle: | 120° |
| Luminous flux: | 750 lm |
| Light intensity: | 411 cd |
| Colour rendering: | 90 CRI |
| Lifetime: | 38000 h |
| Protection class: | IP67 |
| Energy efficiency class: | G |
| Material: | Silicone |
| Indoor and outdoor: | Yes |
| Incl. illuminant: | No |
| Special features: | Separation point: 50mm with 12 SMD each | Pitch (light point center-center): 8.34mm | 1 unit (roll) = 3m | max. flex stripe length per feed: 5m | length tolerance + thermal expansion: 1% | no cooling profile required | without adhesive tape! | silicone potting | SPECIAL FEATURE: 30cm 2-pole sheathed cable one-sided, white, connection on the side, open stranded wire without MiniAmp connector | NOTE: in width and height 2x1mm applying end caps, vertically bendable (bending radius min. 60mm) | enclosed accessories: 1 end cap without cable bushing, incl. sealant |
